UltraEco – 86L830BPT Ultra‑Low Freezer
The UltraEco – 86L830BPT “CryoGuard 830” is a high‑performance ultra‑low temperature (ULT) freezer designed for critical sample preservation. With a capacity of 830 L (≈ 29.3 cu ft), it operates reliably at temperatures from –40 °C down to –86 °C, while employing hydrocarbon (HC) refrigerants and frequency‑conversion technology to minimize energy use. It is ENERGY STAR certified and optimized for reduced noise, fast recovery, and multi‑level security for biological, pharmaceutical, and research applications.
| Area of Use | Biobanks & Diagnostic Centers, Hospitals, Large Hospitals & Medical Colleges, Research Laboratories |
|---|---|
| Model | DW-86L830BPT |
| Configuration | vertical |
| Number of doors | 1-Door |
| Capacity | 830 L |
| Temperature uniformity | ± 2 °C |
| Height | 1980 mm |
| Depth | 998 mm |
| Width | 1145 mm |
| Weight | ~380 kg |
| Power consumption | 5.18 kW |
| Power supply | 100~230/50/60 |
| Shelves/ Inner doors | 3/4 |
Product Description
The Haier UltraEco ULT‑86 830L (model DW‑86L830BPT) is a high-quality ultra-low temperature freezer designed to safely store valuable biological materials like vaccines, DNA samples, enzymes, reagents, and other sensitive medical or research items. With a large 830-liter capacity, it’s perfect for labs, biobanks, and research facilities that need reliable long-term storage at ultra-low temperatures, going as low as -86°C. One of the key highlights of this model is its energy-efficient hydrocarbon (HC) refrigeration system, which not only cools effectively but also uses less power and is more environmentally friendly.
This freezer is built with thick insulation and vacuum panels, which help keep the temperature stable and extend the safe storage time even during a power outage. To protect your samples, it includes multiple safety features like alarms for high or low temperatures, door left open, power failure, and system issues. There’s also a lockable door and optional password protection to prevent unauthorized access.
The touchscreen control panel is easy to use and shows real-time temperature, alerts, and data logs so you can keep track of your samples at all times. It’s also designed with user comfort in mind, featuring quiet operation, soft-close doors, and strong wheels for easy movement. In short, the Haier UltraEco ULT‑86830L combines strong performance, safety, energy savings, and ease of use—making it a smart and dependable choice for any lab or facility that stores critical biological materials.
Variants
| Model No. | Capacity (L/Cu.Ft) | Power Supply (V/Hz) | Display | Certificate | Drawers/Baskets | Blood Bags (ml*pcs) |
|---|---|---|---|---|---|---|
| DW-86L730BPT | N/A | N/A | N/A | N/A | N/A | N/A |
